UMEVO Note Plus
AI-Powered Voice Recorder User Manual
1. Introduction
Welcome to the UMEVO Note Plus, your smart AI-powered voice recorder. This device is designed to help you capture high-quality audio for meetings, calls, and personal notes, and then seamlessly transcribe and summarize them with the power of AI.
AI-Powered Transcription
Get accurate transcriptions and summaries in 140 languages, powered by ChatGPT with 99% accuracy rate.
Dual-Mode Recording
Easily switch between recording meetings (NOTE mode) and phone calls (CALL mode).
Long-Lasting Battery
Record for up to 40 hours on a single charge with 60 days standby time.
Ample Storage
64GB of internal storage, plus unlimited cloud storage for your recordings.
2. What's in the Box
3. Getting Started
Download the App
Search for "AI DVR Link" in the App Store or Google Play to download and install the companion app.
Charging the Device
Connect the magnetic charging cable to the charging port on the device and a USB power source. A full charge takes approximately 1.5 hours.
Powering On/Off
Long press the Power/Record button for 3 seconds to turn the device on or off. A "Welcome" message will appear on the screen when powered on.
Binding the Device
Enable Bluetooth on your phone, open the "AI DVR Link" app, and follow the on-screen instructions to bind your UMEVO Note Plus. A successful connection is indicated by the Bluetooth icon on the device's screen.
4. Recording
4.1 Recording Modes
NOTE Mode
Toggle the switch to the right for general-purpose recording, such as in meetings or lectures. Hold the recorder in your hand or place it on a desk to start recording.
CALL Mode
Toggle the switch to the left for recording phone calls. For best results, attach the recorder to the back of your phone using the magnetic case to capture phone vibrations.
4.2 How to Record
On the Device
- Start Recording: Short press the Power/Record button (you'll feel one vibration)
- Stop Recording: Short press the button again (you'll feel two vibrations)
In the App
- Start/Stop: Tap the "Record" button in the app
- Pause/Resume: Tap once during recording to pause, tap again to resume
-
Save: Tap the Save button to finish and save the recording
4.3 File Synchronization
Once connected to the app, your audio files will automatically sync and appear in the app's file list. The device features auto-reconnection, so no repeated pairing is required for subsequent recordings.
Recorder File Sync via Computer
Connect the recorder to your computer using the USB cable.
1. The recorder powers on automatically.
2. A connection icon appears on the screen.
3. For initial connection:
- Computer prompts for driver installation.
- Wait until "My Computer" (Windows) recognizes a new drive.
4. When connection is confirmed:
- Transfer files via drag-and-drop.
- Read/manage files normally.
Notice:
Never disconnect during file transfer to prevent data loss.
5. AI Features
5.1 Transcription & Summarization
After syncing a file, tap on it in the app to initiate transcription. Once transcription is complete, a summary and mind map will be generated automatically using advanced AI technology powered by ChatGPT.
5.2 Managing Files
You can rename, move, and edit your files within the app. If you're not satisfied with the transcription or summary, you can re-process the file (this will use your transcription minutes) or manually edit the content.
5.3 Exporting Files
Audio
WAVTranscript
TXT Markdown DOCX PDFSummary
TXT SRT DOCX PDFMind Map
JPEG Markdown6. Technical Specifications
| Battery Capacity | 400 mAh |
| Recording Time | Up to 40 hours |
| Standby Time | Up to 60 days |
| Storage Capacity | 64GB (400 hours audio) |
| Recording Format | MP3, WAV |
| Audio Bit Rate | 32 Kbps |
| Charging Method | Magnetic charging |
| Charging Time | ~1.5 hours |
| Weight | 30g |
| Supported Systems | iOS, Android, Windows, Linux |
| Rated Input | DC 5V 1A |
7. Frequently Asked Questions
How accurate is the AI transcription?
The UMEVO Note Plus achieves an accuracy rate of over 99% for transcription under optimal conditions. Accuracy may vary slightly depending on factors such as background noise, speaker clarity, and accents. Our advanced AI noise cancellation technology significantly enhances accuracy even in challenging environments.
What languages are supported for transcription and translation?
The UMEVO Note Plus supports transcription and translation in 140 languages, including English, Spanish, French, German, Chinese (Mandarin and Cantonese), Japanese, Korean, Arabic, Russian, Portuguese, Italian, Dutch, Hindi, and many more.
How long does the battery last?
The device features a 400 mAh rechargeable battery providing up to 40 hours of continuous recording on a single charge. In standby mode, it lasts up to 60 days. The device charges fully in approximately 1.5 hours.
What file formats does the recorder support?
The UMEVO Note Plus supports standard audio formats such as MP3 and WAV. Transcribed text can be exported as TXT, DOCX, or PDF files for easy use across various devices and applications.
Is there a subscription fee for using the AI features?
Your purchase includes 400 minutes of AI transcription and summarization per month at no additional cost. Flexible subscription plans are available for high-volume users requiring additional transcription time. All other features remain free.
8. Support and Warranty
30-Day Money-Back Guarantee
Return your device for any reason within 30 days for a full refund with free return shipping.
1-Year Warranty
The UMEVO Note Plus is covered by a comprehensive one-year manufacturer's warranty.
Lifetime Customer Support
Contact us anytime for assistance. Quick support within 24 hours on working days.
Free Worldwide Shipping
Fast, free shipping worldwide. Orders typically shipped within 1-2 business days.
